Tree Traversal
From Wikipedia: Tree traversal
- In-order, pre-order, and post-order are 3 common forms of depth-first tree traversal.
- While traversing a non-linear data structure (such as a tree) we have choices for which node to visit next.
- Therefore, we must store references to nodes we’re not visiting yet for later retrieval.
- This is commonly done explicitly in a stack or queue, or implicitly in the call stack of a recursive function.
- Depth-first search is easily implemented with a stack (explicitly or implicitly via the call stack).
- The sequence of nodes visited in a tree traversal is called a trace.
- None of these 3 traversal orders produces a trace that uniquely defines a tree.
🤔 Interesting. This fact doesn’t seem obvious to me.
Given a tree with distinct elements, either pre-order or post-order paired with in-order is sufficient to describe the tree uniquely. However, pre-order with post-order leaves some ambiguity in the tree structure.
🤔 Okay, so pre-order and post-order traversals have some sort of structural similarity that isn’t shared with an in-order traversal.
Depth-First Traversal Orders
In depth-first traversals, the children sub-trees are searched recursively.
Mnemonics
- Pre-order visits the parent node before (hence pre) the children.
- Post-order visits the parent node after (hence post) the children.
- In-order visits the parent node in-between the children.
- also: in-order traversal would return the elements of a binary search tree in order.
Pre-order
flowchart
1 --> 2
1 --> 3
Post-order
flowchart
3 --> 1
3 --> 2
In-order
flowchart
2 --> 1
2 --> 3
Reverse pre-order
flowchart
3 --> 2
3 --> 1
Reverse post-order
flowchart
1 --> 3
1 --> 2
Reverse in-order
flowchart
2 --> 3
2 --> 1
Level-order
AKA Breadth-first search (BFS)
