2026-04-13 | 🦋 Fixing Bluesky Link Facet Offsets 🔗
🐛 The Bug
🔵 On Bluesky, link URLs in posts were visually misaligned.
👀 A few characters before the URL appeared blue, and a few characters at the end of the URL were not blue.
🧠 The link card embed below the post worked fine, but the inline URL text had broken highlighting.
🔍 Root Cause Analysis
🏗️ Bluesky uses the AT Protocol, which requires explicit byte-offset annotations called facets for rich text.
📏 Every URL in a post needs a facet specifying its exact UTF-8 byte start and byte end positions.
🔢 The original implementation split the post text into words using a standard text splitting function, then walked through tokens, adding 1 byte per gap between words to track positions.
🤔 Why Did the Offsets Drift?
1️⃣ The text splitting function collapses all whitespace into single separators, whether the original text had one space, one newline, or two newlines.
2️⃣ The assembled post text uses double newlines between the title, question, and tags sections, creating visual paragraph breaks.
3️⃣ Each double newline is 2 bytes, but the code only counted 1 byte per gap, so the calculated position fell behind by 1 byte per collapsed newline.
4️⃣ With two paragraph breaks before the URL, the byte offset was 2 bytes too low, making the facet start 2 characters before the URL and end 2 characters before the URL end.
5️⃣ This was never caught because the facet detection had no tests, and the drift is only noticeable when the text has multi-byte whitespace gaps before the URL.
🔧 The Fix
🎯 Replaced the word-splitting approach with direct URL search.
🔎 The new implementation scans the text for protocol prefixes like https colon slash slash and http colon slash slash.
📐 For each URL found, it encodes the prefix text before the URL into UTF-8 bytes and measures the byte length directly.
✅ This avoids any assumptions about whitespace normalization and produces correct byte offsets regardless of how many newlines, spaces, or emoji characters appear before the URL.
🧪 Testing
📋 Added 12 unit tests covering URL detection at the start, middle, and end of text.
🔢 Tests verify correct byte offsets with single newlines, double newlines, and multi-byte emoji characters.
🐛 One test reproduces the exact bug scenario from the issue, with emojis and double newlines matching the real post format.
🎲 Added 2 property-based tests: one verifying that byte offsets correctly slice the URL from encoded text for arbitrary prefixes, and another verifying that text without protocol prefixes produces no facets.
💡 Lessons Learned
📏 When working with byte offsets, never assume whitespace is a single byte, especially when the text may contain newlines, tabs, or other multi-byte sequences.
🧩 Text splitting functions that normalize whitespace are useful for tokenization but dangerous for position tracking.
🔬 Pure functions that compute byte offsets should always be tested with property-based tests, since edge cases with multi-byte characters and mixed whitespace are easy to miss.
🏗️ The AT Protocol documentation is explicit about using UTF-8 byte offsets, not character offsets, which is an important distinction when working with emoji-heavy social media text.
