2026-04-12 | 🖼️ Forward-Compatible Image Backfill & Propagation Delay 🏎️
🎯 The Problem
🔍 Two related issues emerged in the automation pipeline that generates cover images for blog posts and decides when those posts are ready for social media.
📂 First, the image backfill system used a hardcoded Haskell sum type called ContentDirectory with exactly thirteen constructors, one for each known content directory. 🆕 Every time a new auto blog series was added through a JSON config file, someone had to manually add a new constructor to this type, update the round-trip text functions, and adjust the test count. 🚫 This was the opposite of forward-compatible.
🏎️ Second, when a note received a freshly generated image, the social posting system would immediately consider it ready to post. ⏰ But GitHub Pages deployments take time, so the image might not yet be live on the website when the social media post goes out. 👀 Followers clicking through would see a page without its cover image.
🔧 The Solution
🏷️ Extending ContentDirectory with AutoBlogSeries
🧠 The key insight was that the ten core content directories like Reflections, Books, and AiBlog are truly a closed set of well-known directories, but auto blog series are an open set discovered at runtime from JSON configs. 💡 Rather than abandon the strongly typed ContentDirectory ADT entirely, we added a single parameterized constructor: AutoBlogSeries Text. 🔒 This preserves type safety for the known directories while allowing new series to be represented without code changes. 🚫 Auto blog series like chickie-loo, auto-blog-zero, and systems-for-public-good are intentionally excluded from the closed set to avoid duplicating what the JSON configs already declare.
🔀 The imageBackfillContentDirsFrom function now derives the full list of content directories by combining the known constructors with AutoBlogSeries wrappers around each discovered series identifier. 📦 The round-trip functions contentDirectoryToText and contentDirectoryFromText handle the mapping between the ADT and the filesystem directory names, falling back to AutoBlogSeries for any unrecognized name.
🔗 Threading ContentDirectory Through Social Posting
🐛 The autoPost and runPostingPipeline functions previously took a list of Text content identifiers, but the social posting image gate was not properly checking auto blog series directories. 🔧 Both functions now accept a list of ContentDirectory values. 📋 RunScheduled passes the same dynamically-computed list to both the image backfill task and the social posting task, ensuring consistent behavior.
⏰ Image Propagation Delay
🆕 A new noteImageDate field was added to the ContentNote record, storing a full UTCTime value parsed from the image_date frontmatter field. 🕐 This preserves second-level precision from the original timestamp rather than truncating to just a date.
🔍 The isAwaitingImageBackfill function was expanded to check not just whether a note lacks an image, but also whether it has an image generated too recently. 📏 If the time since image generation is less than 86400 seconds (one day), the note is still considered to be awaiting propagation. ✅ This gives GitHub Pages ample time to deploy the image before the note gets posted to social media.
🧹 Renaming Fields for Clarity
📛 All ContentNote fields were renamed from the abbreviated prefix pattern (cnFilePath, cnTitle, cnUrl) to full descriptive names (noteFilePath, noteTitle, noteUrl). 📖 This follows the no-abbreviations rule and makes the code more readable throughout the social posting module and all its callers.
🧪 Testing
🔬 All existing tests were updated for the new field names and ContentDirectory types. 📊 New tests verify the propagation delay behavior with second-precision timestamps, confirming that recently generated images defer posting and that images older than one day are considered propagated. ✅ All 1577 tests pass with zero hlint hints.
🎓 Lessons Learned
🏷️ When a set has a known core plus an open extension point, a sum type with a parameterized fallback constructor is the sweet spot between full static typing and stringly-typed systems. 🔒 The known constructors get exhaustive pattern matching while the fallback handles the dynamic portion.
🏎️ Race conditions between pipeline stages are easy to miss. 🔍 Image generation, website deployment, and social posting are three separate processes with no shared transaction boundary. ⏰ A simple time-based delay is more robust than checking the live website because it accounts for deployment queues, CDN propagation, and transient failures.
🕐 Preserving timestamp precision matters. 📅 Truncating a datetime to just a date loses the ability to reason about sub-day delays. 🔬 Using UTCTime with diffUTCTime provides exact elapsed-time arithmetic regardless of timezone.
