2026-04-10 | 🎨 Separating Data from Behavior in Image Providers 🧩

🔍 The Problem

🎯 The Haskell codebase had an ImageProviderConfig data type that embedded IO callback functions directly in its fields. 🧱 Two of its fields were functions: one for generating images and one for optionally describing content via Gemini. 🚫 Because functions cannot be compared or printed, ImageProviderConfig could not derive Show or Eq, making it fundamentally untestable as data.

💡 The Approach

🧠 Three candidate plans were evaluated before settling on the best one.

📋 Plan one was a minimal replacement of IO callbacks with a dispatch pattern, keeping everything in the BlogImage module. 📦 Plan two proposed extracting a new module for the provider ADT. 🔧 Plan three would have also renamed all field prefixes and switched to qualified imports across the board.

✅ Plan one won because it directly addresses the architectural goal with the smallest possible diff and lowest risk. 🎯 The key insight is that the five image providers form a closed set, which is exactly the pattern that algebraic data types excel at modeling.

🏗️ What Changed

🆕 A new ImageProvider algebraic data type was introduced with five constructors: Cloudflare carrying its account ID, HuggingFace, Together, Pollinations, and GeminiImage. 🏷️ A providerName function maps each constructor to its display name for logging, replacing the old text field.

📝 A new PromptDescriber record was defined to hold the Gemini API key and model as pure data. 🔒 Its Show instance inherits redaction from the Secret type, so API keys never leak into logs.

🔄 ImageProviderConfig was rewritten with three changes. 🗑️ The ipcName text field was replaced with an ipcProvider field of type ImageProvider. 🗑️ The ipcGenerator IO callback was removed entirely. 🗑️ The ipcDescribePrompt IO callback was replaced with an ipcDescriber field holding an optional PromptDescriber.

🎯 A new generateImage function dispatches to the correct HTTP generator by pattern matching on the ImageProvider constructor. 🎯 A new describeContent function dispatches to Gemini using the PromptDescriber’s pure data fields. 🧹 All five provider resolver functions were simplified to construct pure data instead of closing over IO callbacks. 🔗 All callers were updated to use the new dispatch functions.

🧪 Testing

✅ Twenty-two new tests were added covering three areas.

🔍 Eleven tests cover the ImageProvider type: providerName returns the correct text for all five constructors, Cloudflare carries its account ID, Eq distinguishes constructors, and Show includes constructor names.

🔒 Four tests cover PromptDescriber: Show redacts the API key, Show contains model information, Eq compares by value, and Eq distinguishes different models.

⚙️ Seven tests cover ImageProviderConfig: Show works and redacts secrets, Eq compares by value, configs with a Gemini key get a describer, configs without a Gemini key get no describer, Cloudflare configs carry the account ID, and Gemini configs have the GeminiImage provider type.

📊 All 1112 tests pass, up from 1090 before this change.

🎓 Lessons Learned

🔄 When a data structure embeds IO callbacks, replace them with a closed ADT and a dispatch function. 📏 The ADT captures the what, and the dispatch function captures the how. 🧪 This makes the data structure derivable for Show and Eq, which is proof of purity.

🧩 When every variant of a config carries the same optional callback, that callback is a cross-cutting concern. 📦 Extract it as its own pure data record with its own dispatch function, making the relationship explicit rather than implicit.

📐 Successfully deriving Show and Eq after a refactor is a mechanical proof that no IO has been left behind. 🚫 If the compiler refuses to derive these instances, there is still hidden behavior embedded in the data.
